A-115
Appendices
NJ-series CPU Unit Software User’s Manual (W501)
A-10 Size Restrictions for the User Program
App
A-10-2 Counting User Program Objects
Variables with a Retain attribute are counted as described below.
 Objects Counted as Variables with a Retain Attribute
The following objects are counted as variables with a Retain attribute.
• Global variables with a Retain attribute
• Local variables with a Retain attribute in programs and function block instances (both user-cre-
ated instances and instructions are included)
 Precautions in Counting Variables with a Retain Attribute
Observe the following precautions when you count variables with a Retain attribute.
• Count arrays as one variable each regardless of the number of elements.
• Do not count arrays of function block instances. However, count one variable for each element of
the array for the number of variables with a Retain attribute that are used in the function blocks.
Data type definitions are counted as described below.
 Objects Counted as Data Type Definitions
The following objects are counted as data type definitions.
• User-created structure definitions
• User-created union definitions
• User-created enumeration definitions
Number of Variables with a Retain Attribute
Number of Data Type Definitions
