2 CPU Unit Operation
2-30
NJ-series CPU Unit Software User’s Manual (W501)
 Checking the Operating Mode from the Sysmac Studio
You can check the operating mode from the Controller Status Pane of the Sysmac Studio. The fol-
lowing Controller Status Pane indicates that the CPU Unit is in RUN mode.
Additional Information
If you want to output a signal when the CPU Unit is in RUN mode, use the RUN output on the
Power Supply Unit. Refer to the NJ-series CPU Unit Hardware User’s Manual (Cat. No. W500)
for details on the RUN output on the Power Supply Unit.

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
