5 I/O Memory

5-28

CP2E CPU Unit Software User’s Manual(W614)

z Using the Clock Pulses

The following example turns a bit ON and OFF at 0.5-s intervals.

P_1s

100.00

Instruction

Operand

LD P_1s

OUT 100.00

0.5s 0.5s

100.00
