7 PLC Setup
CP2E CPU Unit Software User’s Manual(W614)
7-2 PLC Setup Settings
7
7-2-4 Serial Option Port 1/Built-in RS-232C
Port
2 2-5 2-5-2 Format
(data length, stop bits, par-
ity)
7 bits, 2 bits, even 7 bits, 2 bits, even When power is turned ON
7 bits, 2 bits, odd
7 bits, 2 bits, no parity
7 bits, 1 bit, even
7 bits, 1 bit, odd
7 bits, 1 bit, no parity
8 bits, 2 bits, even
8 bits, 2 bits, odd
8 bits, 2 bits, no parity
8 bits, 1 bit, even
8 bits, 1 bit, odd
8 bits, 1 bit, no parity
2-5-3 Response Timeout 5 s 0 (5 s) When power is turned ON
1 (×100 ms)
:
255 (×100 ms)
2-6 PC Link (Slave) Settings
2-6-1 Baud 9,600 bps 1,200 bps When power is turned ON
2,400 bps
4,800 bps
9,600 bps
19,200 bps
38,400 bps
57,600 bps
115,200 bps
2-6-2 PLC Link Unit No. 0 0 When power is turned ON
:
7
2-7 PC Link (Master) Settings
2-7-1 Baud 9,600 bps 1,200 bps When power is turned ON
2,400 bps
4,800 bps
9,600 bps
19,200 bps
38,400 bps
57,600 bps
115,200 bps
2-7-2 Link Words 10 Words 1 word When power is turned ON
:
10 words
2-7-3 PC Link Mode ALL ALL When power is turned ON
Masters
2-7-4 No.NT/PC Link Max.
(Highest unit number of PT
that can be connected to
the PLC)
0 0 When power is turned ON
:
7
