Omron SYSMAC CP Series - 15-6-4 PLC Setup for DNS and Automatic clock Adjustment

15 Ethernet
15-56
CP2E CPU Unit Software User’s Manual(W614)
z DNS Setting
Move the cursor to the Settings and double click. Select the Built-in Ethernet Tab. Click the DNS
Setting button to display the DNS setup dialog.
z Clock Auto Adjustment
Move the cursor to the Settings and double click. Select the Built-in Ethernet Tab. Click the Clock
Auto Adjustment button to display the Clock Auto Adjustment setup dialog.
CX-Programmer Setup
Item Contents Default
IP Address Set the IP address for the DNS server.
The DNS server is required when specifying the SNTP servers by
host name.
None
Port No. Set the port to be used for connecting to the DNS server.
This setting does not normally need to be changed.
0
(Number 53 is used.)
Retry timer Set the time to elapse before retrying when a connection to the
DNS server fails.
This setting does not normally need to be changed.
0 (10 s)
