18-17

18 Programming Device Operations

CP2E CPU Unit Software User’s Manual(W614)

18-3 Creating a Ladder Program

18-3-3 Editing Ladder Programs

Comments can be added to rungs in the program.

Inputting Rung Comments

Double-click the header of the rung

to which a comment is to be

attached.

The Rung Properties Dialog Box will

be displayed.

Input a comment into the Comment

Field on the General Tab Page.

Close the Rung Properties Dialog

Box.

The input rung comment will be dis-

played in the ladder program.
