5-7
5
S1-01
Follower
Mode Selec-
toin
Sets the Speed Follower operatoin mode
0: Disabled
Follower mode is disabled and the
drive runs from the normal fre-
quency reference.
1: Speed - Both Directions
The drive follows the master encoder
speed in both directions.
2: Speed - Forward Direction
The drive follows the master encoder
speed in the forward direction only.
3: Speed - Absolute Value
The drive follows the master encoder
speed but ignores the master encoder
direction (always forward direction)
0 to 3 0 No Q Q Q Q 680H
Follower
Mode
S1-02
Master
encoder PPR
Sets the master drive encoder PPR.
20 to
60000
1024 No Q Q Q Q 681H
Master PG
PPR
S1-03
Ratio
Numerator
(Upper 4
Digits)
Sets the upper 4 digits of the primary
gear ratio numerator.
0 to
9999
1000 Yes Q Q Q Q 682H
Ratio Num
High
S1-04
Ratio
Denomina-
tor (Upper 4
Digits)
Sets the upper 4 digits of the primary
gear ratio denominator
0 to
9999
1000 Yes Q Q Q Q 683H
Ratio Den
High
* 1. The setting ranges for acceleration/deceleration times depends on the setting C1-10 (Acceleration/deceleration time setting unit). If C1-10 is set to 0, the
setting range is 0.00 sto 600.00 sec.
* 2. The given setting range is valid if Heavy Duty is selected (C6-01=0, default setting). If Normal Duty 1 or 2 is selected (C6-01=1 or 2) the setting range
will be 0.0 to 400.0Hz.
* 3. The values are for a 200 V class Inverter. Values for a 400 V class Inverter are double.
* 4. The factory setting will change when the control method is changed. (Open Loop Vector control factory settings are given.)
* 5. After autotuning, E1-13 will contain the same value as E1-05.
* 6. The setting range depends on the Inverter capacity (The value for a 200 V class Inverter of 0.4 kW is given.)
* 7. The factory setting depends on the Inverter capacity (The value for a 200 V class Inverter of 0.4 kW is given.)
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO
BUS
Regis-
ter
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
