6-113
6
 Setting the V/f Pattern 1
Using the E1- parameters the Inverter input voltage and the V/f pattern can be set as needed. It is not rec-
ommended to change the settings when the motor is used in Open Loop or Closed Loop vector control mode.
Related Parameters
Setting Inverter Input Voltage (E1-01)
Set the Inverter input voltage correctly in E1-01 so that it matches the power supply voltage. This set value
will be the reference value for the protection functions and similar functions (overvoltage level, stall level).
Parameter
No.
Name
Factory
Setting
Change
during
Opera-
tion
Control Methods
V/f
V/f with
PG
Open
Loop
Vector
Closed
Loop
Vector
E1-01 Input voltage setting
200 V
* 1
* 1. The dacgadsfg values are for a 200 V class Inverter. Values for a 400 V class Inverter are double.
NoQQQQ
E1-03 V/f pattern selection F No Q Q No No
E1-04 Max. output frequency (FMAX) 50.0 Hz No Q Q Q Q
E1-05 Max. voltage (VMAX)
200.0 V
*1
NoQQQQ
E1-06 Base frequency (FA) 50.0 Hz No Q Q Q Q
E1-07 Mid. output frequency (FB)
2.5 Hz
* 2
* 2. The factory setting will change when the control method is changed. (V/f control factory settings are given.)
No A A A No
E1-08 Mid. output frequency voltage (VB)
15.0 V
*1 *2
No A A A No
E1-09 Min. output frequency (FMIN)
1.2 Hz
*2
NoQQQA
E1-10 Min. output frequency voltage (VMIN)
9.0 V
*1 *2
No A A A No
E1-11 Mid. output frequency 2
0.0 Hz
* 3
* 3. Parameter is disregarded when set to 0.0.
NoAAAA
E1-12 Mid. output frequency voltage 2
0.0 V
*3
NoAAAA
E1-13 Base voltage (VBASE)
0.0 V
*3 * 4
* 4. E1-13 is set to the same value as E1-05 after autotuning.
NoAAQQ
