9-2
9
Standard Inverter Specifications
The standard Inverter specifications are listed by capacity in the following tables.
îš‹ Specifications by Model
Specifications are given by model in the following tables.
200V Class
* 1. The maximum applicable motor output is given for a standard 4-pole Yaskawa motor. When selecting the actual motor and Inverter, be sure that the
Inverter's rated current is applicable for the motor's rated current.
* 2. A transformer with dual star-delta secondary is required on the power supply for 12-pulse rectification.
Model Number CIMR-F7Z  20P4 20P7 21P5 22P2 23P7 25P5 27P5 2011 2015 2018 2022 2030 2037 2045 2055 2075 2090 2110
Max. applicable motor out-
put (kW)
*1
0.55 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90 110
Rated output capacity
(kVA)
1.2 1.6 2.7 3.7 5.7 8.8 12 17 22 27 32 44 55 69 82 110 130 160
Rated output current 3.2 4.1 7.0 9.6 15 23 31 45 58 71 85 115 145 180 215 283 346 415
Max. output voltage (V)
3-phase; 200, 220, 230, or 240 VAC
(Proportional to input voltage.)
Max. output frequency
(Hz)
Heavy Duty (low carrier, constant torque applications): 150 Hz max
Normal Duty 1 or 2 (high/reduced carrier, variable torque applications): 400 Hz max.
Rated voltage (V)
Rated frequency (Hz)
3-phase, 200/220/230/240 VAC, 50/60 Hz
Rated input current (A) 3.8 4.9 8.4 11.5 18 24 37 52 68 84 94 120 160 198 237 317 381 457
Allowable voltage fluc-
tuation
+ 10%, - 15%
Allowable frequency
fluctuation
±5%
Mea-
sures for
power
supply
harmon-
ics
DC reactor Optional Built in
12-pulse
rectification
Not possible
Possible
*2
O
utput rat
i
ngsPower supp
l
y c
h
aracter
i
st
i
cs
C
ontro
l
c
h
aracter
i
st
i
cs
