9-3
9
400 V Class
* 1. The maximum applicable motor output is given for a standard 4-pole Yaskawa standard motor. When selecting the actual motor and Inverter, be sure
that the Inverter's rated current is higher than the motor's rated current.
* 2. A transformer with dual star-delta secondary is required on the power supply for 12-pulse-rectification.
Model Number CIMR-F7Z  40P4 40P7 41P5 42P2 43P7 44P0 45P5 47P5 4011 4015 4018
Max. applicable motor output
(kW)
*1
0.55 0.75 1.5 2.2 3.7 4.0 5.5 7.5 11 15 18.5
Rated output capacity
(kVA)
1.4 1.6 2.8 4.0 5.8 6.6 9.5 13 18 24 30
Rated output current (A) 1.8 2.1 3.7 5.3 7.6 8.7 12.5 17 24 31 39
Max. output voltage (V) 3-phase; 380, 400, 415, 440, 460, or 480 VAC (Proportional to input voltage.)
Max. output frequency
(Hz)
Heavy Duty (low carrier, constant torque applications): 150 Hz max.
Normal Duty 1 or 2 (high/reduced carrier, variable torque applications): 400 Hz max.
Rated voltage (V)
Rated frequency (Hz)
3-phase, 380, 400, 415, 440, 460 or 480 VAC, 50/60 Hz
Rated input current (A) 2.2 2.5 4.4 6.4 9.0 10.4 15 20 29 37 47
Allowable voltage fluctua-
tion
+ 10%, - 15%
Allowable frequency fluc-
tuation
±5%
Measures
for power
supply
harmonics
DC reactor Optional
12-phase rec-
tification
Not possible
Model Number CIMR-F7Z 
4022 4030 4037 4045 4055 4075 4090 4110 4132 4160 4185 4220 4300
Max. applicable motor output
(kW)
*1
22 30 37 45 55 75 90 110 132 160 185 220 300
Rated output capacity
(kVA)
34 46 57 69 85 110 140 160 200 230 280 390 510
Rated output current (A) 45 60 75 91 112 150 180 216 260 304 370 506 675
Max. output voltage (V) 3-phase, 380, 400, 415, 440, 460, or 480 VAC (Proportional to input voltage.)
Max. output frequency
(Hz)
Heavy Duty (low carrier, constant torque applications): 150 Hz max.
Normal Duty 1 or 2 (high/reduced carrier, variable torque applications): 400 Hz max.
Max. voltage (V)
Rated frequency (Hz)
3-phase, 380, 400, 415, 440, 460, or 480 VAC, 50/60 Hz
Rated input current (A) 50 66 83 100 120 165 198 238 286 334 407 537 743
Allowable voltage fluctua-
tion
+ 10%, - 15%
Allowable frequency fluc-
tuation
±5%
Measures
for power
supply
harmonics
DC reactor Built in
12-phase rec-
tification
Possible
*2
O
utput rat
i
ngsPower supp
l
y c
h
aracter
i
st
i
cs
Control characteristics
O
utput rat
i
ngsPower supp
l
y c
h
aracter
i
st
i
cs
C
ontro
l
c
h
aracter
i
st
i
cs
