5-81
5
îš‹ Parameter Initial Values that Change With the Setting of C6-01
Param-
eter
Number
Name Unit Factory Setting
- Inverter Capacity kW 110 132 160 185 220 300
o2-04 kVA selection - 32 33 34 35 36 37
b8-03
Energy-saving filter time con-
stant
sec 2.00 (Open Loop vector)
b8-04 Energy-saving coefficient -
32.79 33.18
30.13 30.57 27.13 21.76
C6-02
Carrier fre-
quency
selection
Normal Duty 1 -
32
2211
Normal Duty 2 -
22
2111
E2-01
(E4-01)
Motor rated current A
190.0 223.0
270.0 310.0 370.0 500.0
E2-02
(E4-02)
Motor rated slip Hz 1.40 1.38 1.35 1.30 1.30 1.25
E2-03
(E4-03)
Motor no-load current A 49.0 58.0 70.0 81.0 96.0 130.0
E2-05
(E4-05)
Motor line-to-line resistance W
0.046 0.035
0.029 0.025 0.020 0.014
E2-06
(E4-06)
Motor leak inductance % 20.0 20.0 20.0 20.0 20.0 20.0
E2-10
Motor iron loss for torque com-
pensation
W
2150 2350
2850 3200 3700 4700
E2-11
(E4-07)
Motor rated output power kW 110.00
132.00
160.00 185.00 220.00 300.00
L2-02
Momentary power loss ride
through time
- 2.0 2.0 2.0 2.0 2.0 2.0
L2-03 Min. baseblock (BB) time sec 1.7 1.7 1.8 1.9 2.0 2.1
L2-04 Voltage recovery time sec 1.0 1.0 1.0 1.0 1.0 1.0
L8-02 Overheat pre-alarm level °C 100 110 108 95 100 108
Parameter
Number
Name
Initial Value
C6-01=0 (Heavy Duty) C6-01=1 or 2 (Normal Duty 1 or 2)
C6-02 Carrier frequency selection 1
Depends on the inverter rated
power
L3-02 Stall prevention at acceleration level 150% 120%
L3-06
Stall prevention level during run
150% 120%
L8-15 OL2 characteristics at low speed 0 (Disabled) 1 (Enabled)
