1-2
1
Varispeed F7 Introduction
 Varispeed F7 Applications
The Varispeed F7 is ideal for the following applications.
• Fan, blower, and pump applications
• Conveyors, pushers, metal tooling machines, etc.
Settings must be adjusted to the application for optimum operation. Refer to Chapter 4 Trial Operation
 Varispeed F7 Models
The Varispeed F7 Series includes Inverters in two voltage classes: 200 V and 400 V. The maximum motor capacities
vary from 0.55 to 300 kW (42 models).
Table 1.1 Varispeed F7 Models
Voltage
Class
Maxi-
mum
Motor
Capacity
kW
Varispeed F7
Specifications
(Always specify through the protective structure when
ordering.)
Output
Capacity
kVA
Basic Model Number
Open Chassis
(IEC IP00)
CIMR-F7Z
Enclosed Wall-mounted
(IEC IP20, NEMA 1)
CIMR-F7Z
200 V
class
0.55 1.2 CIMR-F7Z20P4
Remove the top and bottom
covers from the Enclosed
Wall-mounted model.
20P41
0.75 1.6 CIMR-F7Z20P7 20P71
1.5 2.7 CIMR-F7Z21P5 21P51
2.2 3.7 CIMR-F7Z22P2 22P21
3.7 5.7 CIMR-F7Z23P7 23P71
5.5 8.8 CIMR-F7Z25P5 25P51
7.5 12 CIMR-F7Z27P5 27P51
11 17 CIMR-F7Z2011 20111
15 22 CIMR-F7Z2015 20151
18.5 27 CIMR-F7Z2018 20181
22 32 CIMR-F7Z2022 20220 20221
30 44 CIMR-F7Z2030 20300 20301
37 55 CIMR-F7Z2037 20370 20371
45 69 CIMR-F7Z2045 20450 20451
55 82 CIMR-F7Z2055 20550 20551
75 110 CIMR-F7Z2075 20750 20751
90 130 CIMR-F7Z2090 20900 –
110 160 CIMR-F7Z2110 21100 –
