User Parameters
Factory settings are given in the following table. These are factory settings for a 200 V Class Inverter with 0.4
kW (open loop vector control).
No. Name
Factory
Setting
Setting
A1-00 Language selection for Digital Operator display 0
A1-01 Parameter access level 2
A1-02 Control method selection 2
A1-03 Initialize 0
A1-04 Password 0
A1-05 Password setting 0
A2-01 to
A2-32
User specified parameters –
b1-01 Reference source selection 1
b1-02 RUN command source selection 1
b1-03 Stopping method selection 0
b1-04 Prohibition of reverse operation 0
b1-05 Operation selection for setting frequencies equal or lower than E1-09 0
b1-06 Control input scan 1
b1-07 Operation selection after switching to remote mode 0
b1-08 Run command selection in programming modes 0
b2-01 Zero speed level (DC injection braking starting frequency) 0.5 Hz
b2-02 DC injection braking current 50%
b2-03 DC injection braking time at start 0.00 s
b2-04 DC injection braking time at stop 0.50 s
b3-01 Speed search selection (current detection or speed calculation) *1
b3-02 Speed search operating current (current detection) *1
b3-03 Speed search deceleration time (current detection) 2.0 s
b3-05 Speed search wait time (current detection or speed calculation) 0.2 s
b3-10 Speed Search Compensation Gain (speed calculation only) 1.10
b3-14 Speed Search Rotating Selection Direction 1
b3-17 Speed search retrial current level 150%
b3-18 Speed search retrial detection time 0.01s
b3-19 Number of speed search retrials 0
b4-01 Timer function ON-delay time 0.0 s
b4-02 Timer function OFF-delay time 0.0 s
b5-01 PID control mode selection 0
b5-02 Proportional gain (P) 1.00
b5-03 Integral (I) time 1.0 s
b5-04 Integral (I) limit 100.0%
b5-05 Differential (D) time 0.00 s
b5-06 PID limit 100.0%
b5-07 PID offset adjustment 0.0%
b5-08 PID delay time constant 0.00 s
b5-09 PID output characteristics selection 0
b5-10 PID output gain 1.0
b5-11 PID reverse output selection 0
