îš‹ Application Parameters: b
îš„Operation Mode Selections: b1
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
b1-01
Reference
source selec-
tion
Sets the frequency reference
input method.
0: Digital Operator
1: Control circuit terminal
(analog input)
2: MEMOBUS communica-
tions
3: Option Card
4: Pulse train input
0 to 4 1 No Q Q Q Q 180H
4-5
6-7
6-68
Reference
Source
b1-02
RUN com-
mand source
selection
Sets the run command input
method.
0: Digital Operator
1: Control circuit terminal
(digital multi function
inputs)
2: MEMOBUS communica-
tions
3: Option Card
0 to 3 1 No Q Q Q Q 181H
4-5
6-12
6-68
Run Source
b1-03
Stopping
method
selection
Used to set the stopping
method used when a stop
command is input.
0: Deceleration to stop
1: Coast to stop
2: DC injection braking stop
(Stops faster than coast to
stop, no regenerative
operation.)
3: Coast to stop with timer
(Run commands are
disregarded during
deceleration.)
0 to 3 0 No Q Q Q Q 182H
4-5
6-14
Stopping
Method
b1-04
Prohibition
of reverse
operation
0: Reverse enabled
1: Reverse disabled
0 to 2
*2
0No
AA A A
183H 6-54
2: Output Phase Rotation
(both rotational directions
are enabled)
ANo A No
Reverse
Oper
b1-05
Operation
selection for
setting fre-
quencies
equal or
lower than
E1-09
Used to set the method of
operation when the
frequency reference input
is less than the minimum
output frequency (E1-09).
0: Run at frequency reference
(E1-09 not effective).
1: STOP (coast to stop)
2: Run at min. frequency.
(E1-09)
3: Run at zero speed (Fre-
quencies below E1-09 are
zero)
0 to 3 0 No No No No A 184H 6-14
Zero-Speed
Oper
b1-06
Control
input scan
Used to set the responsiveness
of the control inputs (forward/
reverse and multi-function
inputs.)
0: Fast reading
1: Normal reading (Can be
used for possible
malfunction due to noise.)
0 or 1 1 No A A A A 185H –
Cntl Input
Scans
