Omron VARISPEED F7 User Manual

5-36
5
 Option Parameters: F
PG Option Setup: F1
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
F1-01
PG constant
Sets the number of PG pulses
per revolution
0 to
60000
1024 No No Q Q Q 380H 6-146
PG Pulses/
Rev
F1-02
Operation
selection at
PG open cir-
cuit (PGO)
Sets the PG disconnection
stopping method.
0: Ramp to stop
(Deceleration to stop using
the deceleration time 1,
C1-02.)
1: Coast to stop
2: Fast stop (using the
deceleration time in C1-
09.)
3: Continue operation (To
protect the motor or
machinery, avoid to use
this setting.)
0 to 3 1 No No A No A 381H 6-146
PG Fdbk
Loss Sel
F1-03
Operation
selection at
overspeed
(OS)
Sets the stopping method
when an overspeed (OS) fault
occurs.
0: Ramp to stop
(Deceleration to stop using
the deceleration time 1,
C1-02.)
1: Coast to stop
2: Fast stop (using the
deceleration time in C1-
09.)
3: Continue operation (To
protect the motor or
machinery, avoid to use
this setting.)
0 to 3 1 No No A No A 382H 6-146
PG Over-
speed Sel
F1-04
Operation
selection at
deviation
Sets the stopping method
when a speed deviation (DEV)
fault occurs.
0: Ramp to stop
(Deceleration to stop using
the deceleration time 1,
C1-02.)
1: Coast to stop
2: Fast stop (using the
deceleration time in C1-
09.)
3: Continue operation (DEV
is displayed and operation
continued.)
0 to 3 3 No No A No A 383H 6-146
PG
Deviation
Sel
F1-05
PG rotation 0: Phase A leads with
forward run command.
(Phase B leads with
reverse run command,
C.C.W.)
1: Phase B leads with
forward run command.
(Phase A leads with
reverse run command,
C.W.)
0 or 1 0 No No A A A 384H 6-146
PG Rotation
Sel
