1-
9
1
îš‹
Enclosed W
all-mounted
Inverters (NEMA1)
Exterior diagrams of the Enclosed W
all-mounted Inverters (NEMA1
) are shown below
.
Fig 1.10 Exterior Diagrams of Enclosed Wall-mounted Inverters
200 V Class Inverters of 22 or 75 kW
400 V Class Inverters of 22 to 160 kW
200 V/400 V Class Inverters of 0.55 to 18.5 kW
Grommet
25
27
