îš„Parameter Setting Ranges that Change With the Setting of C6-01
Parameter Num-
ber
Name
Setting Range
C6-01=0 (Heavy Duty)
C6-01=1 or 2
(Normal Duty 1 or 2)
C6-02 Carrier frequency selection
0, F, 1 to 6 (depends on the
Inverter capacity)
0, F, 0 to 6 (depends on the
inverter rated power)
b5-15 PID sleep function operation level
Upper Limit = 150.0 Hz Upper Limit = 400.0 Hz
b6-01 Dwell frequency at start
b6-03 Dwell frequency at stop
C1-11 Accel./Decel. time switching frequency
C5-07 ASR gain switching frequency
d1- Frequency references
d3-01 Jump frequency 1
d3-02 Jump frequency 2
d3-03 Jump frequency 3
d6-02 Field weakening limit
E1-04 Maximum output frequency
E1-06 Base frequency
E1-07 Middle output frequency
E1-09 Minimum output frequency
E1-11 Middle output frequency 2
E3-02 Motor 2 maximum output frequency
E3-04 Motor 2 base frequency
E3-05 Motor 2 middle output frequency
E3-07 Motor 2 minimum output frequency
L4-01 Frequency detection level
L4-03 Frequency detection bandwidth -150.0 to +150.0 Hz -400.0 to 400.0 Hz
