Omron VARISPEED F7

5-13
5
Timer Function: b4
b3-14
Speed
Search
Rotating
Selection
Direction
Selects the direction for the
Speed Search operation.
0: Speed Search is started using
the rotation direction from
the frequency reference
signal
1: Speed Search is started using
the rotation direction from
the estimated speed during
speed search.
0 or 1 1 No A A A No 19EH 6-56
Bidir
Search Sel
b3-17
Speed
search
retrial cur-
rent level
Sets the current level to retry a
speed search as a percentage,
taking the Inverter rated current
as 100%.
0 to 200 150% No A No A No 1F0H 6-60
SrchRestart
Lvl
b3-18
Speed
search
retrial
detection
time
Sets the time for detection in a
speed search retrial in units of
seconds.
0.00 to
1.00
0.01s No A No A No 1F1H 6-60
SrchRestart
Time
b3-19
Number of
speed
search retri-
als
Sets the number of times that a
speed search can be retried.
0 to 10 0 No A No A No 1F2H 6-60
Num of
SrchRestr
* 1. The factory setting will change when the control mode is changed (V/f control mode factory settings are given).
* 2. The given factory setting is valid if Heavy Duty is selected (C6-01=0, default setting). If Normal Duty 1 or 2 is selected (C6-01=1 or 2) the factory
setting will be 120%.
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Close
d
Loop
Vector
Display
b4-01
Timer func-
tion ON-
delay time
Sets the timer function output
ON-delay time (dead time) for
the timer function input.
Enabled when a timer function
is set in H1- and H2-.
0.0 to
3000.0
0.0 s No A A A A 1A3H 6-98
Delay-ON
Timer
b4-02
Timer func-
tion OFF-
delay time
Sets the timer function output
OFF-delay time (dead band)
for the timer function input.
Enabled when a timer function
is set in H1- and H2-
0.0 to
3000.0
0.0 s No A A A A 1A4H 6-98
Delay-OFF
Timer
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
