5-30
5
Field Weakening: d6
* The given setting range is valid if Heavy Duty is selected (C6-01=0, default setting). If Normal Duty 1 or 2 is selected (C6-01=1 or 2) the setting range will
be 0.0 to 400.0 Hz
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
d6-01
Field weak-
ening level
Sets the inverter output volt-
age when the field weakening
command is input at a digital
input.
Sets the voltage level as a per-
centage taking the voltage set
by the V/f pattern as 100%.
0 to 100 80% No A A No No 2A0H 6-110
Field-Weak
Lvl
d6-02
Field weak-
ening fre-
quency limit
Sets the lower limit of the fre-
quency range where field con-
trol is valid.
The field weakening com-
mand is accepted only at fre-
quencies above this setting
and only when the speed is in
agreement with the current
speed reference.
0.0 to
150.0
*
0.0 Hz No A A No No 2A1H 6-110
Field-Weak
Freq
d6-03
Field forc-
ing function
selection
Enables or disables field forc-
ing function.
0: Disabled
1: Enabled
0 or 1 0 No No No No A 2A2H 6-111
Field Force
Sel
d6-06
Field forc-
ing function
Limit
Sets the upper limit for the
excitation current applied by
the field forcing function.
A setting of 100% is equal to
the motor no-load current.
Field forcing is active during
all types of operation except
DC Injection.
100 to
400
400% No No No A A 2A5H 6-111
FieldForce
Limit
To Next Page
