5-55
5
* The given initial value is valid if Heavy Duty is selected (C6-01=0, default setting). If Normal Duty 1 or 2 is selected (C6-01=1 or 2) the initial value will
be 120%.
L3-04
Stall preven-
tion selec-
tion during
decel
Selects the stall prevention
during deceleration.
0: Disabled (Deceleration as
set. If deceleration time is
too short, a DC-Bus
overvoltage may result.)
1: Enabled (Deceleration is
stopped when the DC-Bus
voltage exceeds the stall
prevention level.
Deceleration restarts when
the voltage falls below the
stall prevention level
again.)
2: Intelligent deceleration
mode (Deceleration rate is
automatically adjusted so
that in Inverter can
decelerate in the shortest
possible time. The set
deceleration time is
disregarded.)
3: Enabled (with Braking
Resistor Unit)
When a braking option (Brak-
ing Resistor, Braking Resistor
Unit, Braking Unit) is used,
always set to 0 or 3.
0 to 3 1 No Q Q Q Q 492H
4-5
6-25
StallP Decel
Sel
L3-05
Stall preven-
tion selec-
tion during
running
Selects the stall prevention
during running.
0: Disabled (Runs as set. With
a heavy load, the motor
may stall.)
1: Deceleration using
deceleration time 1
(C1-02.)
2: Deceleration using deceler-
ationtime 2 (C1-04.)
0 to 2 1 No A A No No 493H 6-48
StallP Run
Sel
L3-06
Stall preven-
tion level
during run
Set the stall prevention during
run operation current level as a
percentage of the Inverter rated
current.
Effective when L3-05 is 1 or 2.
Usually changing this setting is
not necessary.
Reduce the setting when the
motor stalls.
30 to
200
150%
*
No A A No No 494H 6-48
StallP Run
Level
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
