5-76
5
* The unit is set in o1-03 (frequency units of reference setting and monitor
Fault History: U3
U2-13
Operation
status at
fault
The operating status when the
last fault occurred. The format is
the same as for U1-12.
(Cannot be output.)
- Yes Yes Yes Yes 8CH
Inverter Sta-
tus
U2-14
Cumulative
operation
time at fault
The operating time when the last
fault occurred.
1
hr
Yes Yes Yes Yes 8D H
Elapsed
Time
Param-
eter
Number
Name
Description
Output Signal Level During
Multi-Function Analog Output
Min.
Unit
MEMO-
BUS
Register
Display
U3-01
Last fault
The fault content of 1st last fault.
(Cannot be output.)
-90H
Last Fault
U3-02
Second last fault
The fault content of 2nd last fault. - 91H
Fault Message 2
U3-03
Third last fault
The fault content of 3rd last fault. - 92H
Fault Message 3
U3-04
Fourth last fault
The fault content of 4th last fault. - 93H
Fault Message 4
U3-05
Cumulative opera-
tion time at fault
The total operating time when the 1st previous
fault occurred.
1
hr
94H
Elapsed Time 1
U3-06
Accumulated time of
second fault
The total operating time when the 2nd previous
fault occurred.
1
hr
95H
Elapsed Time 2
U3-07
Accumulated time of
third fault
The total operating time when the 3rd previous
fault occurred.
1
hr
96H
Elapsed Time 3
U3-08
Accumulated time of
fourth/oldest fault
The total operating time when the 4th previous
fault occurred.
1
hr
97H
Elapsed Time 4
U3-09
–
U3-14
Fifth last to tenth last
fault
The fault content of the 5th to 10th last fault –
804
805H
806H
807H
808H
809H
Fault Message 5 to 10
U3-15
–
U3-20
Accumulated time of
fifth to tenth fault
Total generating time when 5th ... 10th previous
fault occurred
1hr
806H
80FH
810H
811H
812H
813H
Elapsed Time 5 to 10
IMPORTAN
T
The following faults are not recorded in the Fault Trace and Fault History:
CPF00, 01, 02, 03, UV1, and UV2.
Param-
eter
Num-
ber
Name
Description
Output Signal Level During
Multi-Function Analog Out-
put
Min.
Unit
Control Methods
MEMO-
BUS
Register
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
