6-78
6
îš„Inverter Operation Ready (Setting: 6)
If a multifunction output is programmed for this function the output will be switched ON when the initialisa-
tion of the inverter at startup has finished without any faults.
îš„During DC Bus Undervoltage (Setting: 7)
If a multifunction output is programmed for this function the output is switched ON as long as a DC bus und-
ervoltage is detected.
îš„During Baseblock (Setting: 8)
If a multifunction output is programmed for this function the output is switched ON as long as the inverter out-
put is base blocked.
îš„Frequency Reference Source Selection (Setting: 9)
If a multifunction output is programmed for this function the output is ON when the digital operator is selected
as frequency reference source. If any other frequency reference is selected the output is switched OFF.
îš„Run Command Selection Status (Setting: A)
If a multifunction output is programmed for this function the output is switched ON when the digital operator
is selected as RUN command source. If any other RUN command source is selected output is switched OFF.
îš„Fault Output (Setting: E)
If a multifunction output is programmed for this function the output is switched ON when any fault different
from CPF00 and CPF01 occurs. The output is also not switched at alarms. (Refer to page 7-2 pp. for a fault
list.)
îš„Alarm Output (Setting: 10)
If a multifunction output is programmed for this function the output is switched ON when a alarm occurs
(refer to page 7-10 pp. for an alarm list).
îš„Fault Reset Command Active (Setting: 11)
If a multifunction output is set for this function the output is switched ON as long as a fault reset command is
input at one of the digital inputs.
îš„During Reverse Run (Setting: 1A)
If a multifunction output is programmed for this function the output is switched ON whenever a RUN com-
mand in reverse direction is active. The output will also be ON during DC injection, Braking and Base Block.
It will not work when a forward RUN command is input.
îš„During Base Block 2 (Setting: 1B)
If a multifunction output is programmed for this function the output is switched OFF as long as a Baseblock
command is input at a multifunction input.
