Note: Communications fault details are stored until an fault reset is input (you can also reset while the Unit is operating).
002BH
Control terminals input status
Bit 0 Input terminal S1 1: ON 0: OFF
Bit 1 Input terminal S2 1: ON 0: OFF
Bit 2 Multi-function input terminal S3 1: ON 0: OFF
Bit 3 Multi-function input terminal S4 1: ON 0: OFF
Bit 4 Multi-function input terminal S5 1: ON 0: OFF
Bit 5 Multi-function input terminal S6 1: ON 0: OFF
Bit 6 Multi-function input terminal S7 1: ON 0: OFF
Bits 7 to F Not used
002CH
Inverter status
Bit 0 Operation 1: Operating
Bit 1 Zero speed 1: Zero speed
Bit 2 Frequency agree 1: Agreement
Bit 3 User-defined speed agree 1: Agreement
Bit 4 Frequency detection 1 1: Output frequency ≤ L4-01
Bit 5 Frequency detection 2 1: Output frequency ≥ L4-01
Bit 6 Inverter startup completed 1: Startup completed
Bit 7 Undervoltage detection 1: Detected
Bit 8 Baseblock 1: Inverter output baseblock
Bit 9 Frequency reference mode 1: Not communication 0: Communication option
Bit A Run command mode 1: Not communication 0: Communication option
Bit B Overtorque detection 1: Detected
Bit C Frequency reference lost 1: Lost
Bit D Restart enabled1: Restarting
Bit E Fault (including MEMOBUS communications time-out) 1:Fault occurred
Bit F MEMOBUS communications time-out 1: Timed out
002DH
Multi-function digital output status
Bit 0 Multi-function digital output 1 (terminal M1-M2) 1: ON 0: OFF
Bit 1 Multi-function digital output 2 (terminal M3-M4) 1: ON 0: OFF
Bit 2 Multi-function digital output 3 (terminal M5-M6) 1: ON 0: OFF
Bits 3 to F Not used
002EH - 0030H Not used
0031H Main circuit DC voltage
0032H - 0037H Not used
0038H PID feedback (max. output frequency = 100%; resolution 0.1%; without sign)
0039H PID input (max. output frequency = 100%; resolution 0.1%; with sign)
003AH PID output (max. output frequency = 100%; resolution 0.1%; with sign)
003BH CPU software number
003CH Flash software number
003DH
Communications fault details
Bit 0 CRC fault
Bit 1 Invalid data length
Bit 2 Not used
Bit 3 Parity fault
Bit 4 Overrun fault
Bit 5 Framing fault
Bit 6 Time-out
Bits 7 to F Not used
003EH kVA setting
003FH Control method
Register Address. Contents
