2-5
2
Fig 2.4 Terminal Arrangement of Safety Inverter (200 V/400 V Class Inverter of 22 kW or more)
E(G) S1 S2 S3 S4 S5 S6 S7 FM AC AM IG S+ S-
SN SC SP A1 A2 V+ AC V- MP AC RP R+ R-
M3 M4 M1 M2
M5 M6 MA MB MC
E(G)
BB BB1 SC
Control Circuit Terminals
Main Circuit Terminals
Charge Indicator
Ground Terminals
