2-32
2
îš„ Preventing C Option Card Connectors from Rising
After installing an Option Card into slot C, insert an Option Clip to prevent the side with the connector from
rising. The Option Clip can be easily removed by holding onto the protruding portion of the Clip and pulling it
out.
Fig 2.16 Mounting Option Cards
A Option Card mounting spacer hole
CN4
A Option Card connector
CN2
C Option Card connector
A Option Card mounting spacer
(Provided with A Option Card)
Option Clip
(To prevent raising of
C Option Card)
A Option Card
A Option Card mounting spacer
C Option Card mounting space
