Setting Parameters
Here the procedure to change C1-01 (Acceleration Time 1) from 10 s to 20 s is shown.
Table 3.3 Setting Parameters in Advanced Programming Mode
Step
No.
Digital Operator Display Description
1 Power supply turned ON.
2
Press the MENU key 3 times to enter the advanced programming
mode.
3
4
5 Press the DATA/ENTER to access the monitor display.
6
Press the Increment or Decrement key to display the parameter
C1-01 (Acceleration Time 1).
7
Press the DATA/ENTER key to access the setting display. The cur-
rent setting value of C1-01 is displayed.
8 Press the Shift/RESET key to move the flashing digit to the right.
9 Press the Increment key to change set value to 20.00 s.
10 Press the DATA/ENTER key to save the set data.
11
“Entry Accepted” is displayed for 1 sec after pressing the
DATA/ENTER key.
12 The display returns to the monitor display for C1-01.
Frequency Ref
-DRIVE-
U1-02=50.00Hz
U1-03=10.05A
Rdy
U1- 01=50.00Hz
** Main Menu **
-DRIVE-
Operation
** Main Menu **
-QUICK-
Quick Setting
** Main Menu **
-ADV-
Programming
Initialization
-ADV-
A1-00=1
Select Language
Accel / Decel
-ADV-
Accel Time 1
C1-00 = 10.0sec
Accel Time 1
-ADV-
C1-01 =
0 010.0sec
(0.0 ~ 6000.0)
"10.0 sec"
Accel Time 1
-ADV-
C1-01 =
00 10.0sec
(0.0 ~ 6000.0)
"10.0 sec"
0
Accel Time 1
-ADV-
C1-01 =
001 0.0sec
(0.0 ~ 6000.0)
"10.0 sec"
1
Accel Time 1
-ADV-
C1-01 =
001 0.0sec
(0.0 ~ 6000.0)
"10.0 sec"
2
Entry Accepted
-ADV-
Accel Time 1
-ADV-
C1-01 =
20.0sec
(0.0 ~ 6000.0)
"10.0 sec"
01
