îš„Parameter Settings for Autotuning
The following parameters must be set before autotuning.
* 1. Displayed only, when a motor switch command is set for a multi-function digital input (one of H1-01 to H1-05 set to 16).
* 2. Only setting 2 (non-rotating autotuning for line-to-line resistance only) is possible for V/f control or V/f control with PG.
* 3. Stable vector control will be possible when the setting is between 50% and 100%.
* 4. For an inverter motor or vector control motor, the voltage and frequency may be lower than for a general-purpose motor. Always confirm setting on the
nameplate or in test reports. Also, if you know the no-load values, set the no-load voltage in T1-03 and the no-load frequency in T1-05 to obtain better
accuracy.
* 5. The setting range is valid if Heavy Duty is selected (C6-01=0, default setting). If Normal Duty 1 or 2 is selected (C6-01=1 or 2) the setting range will be
0.0 to 400.0 Hz.
Table 4.3 Parameter Settings before Autotuning
Parame-
ter Num-
ber
Name
Display
Setting
Range
Factory
Setting
Data Displays during Autotuning
Display
V/f
V/f with
PG
Open
Loop
Vector
Closed
Loop
Vector
T1-00
*1
Motor 1/2
selection
Set the location where the auto-
tuned motor data are to be stored.
1: E1 to E2 (motor 1)
2: E3 to E4 (motor 2)
1 or 2 1 Yes Yes Yes Yes
Select
Motor
T1-01
Autotuning
mode selec-
tion
Set the autotuning mode.
0: Rotating autotuning
1: Non-rotating autotuning
2: Non-rotating autotuning for
line-to-line resistance only
0 to 2
2 (V/f and
V/f with
PG)
0 (Open
Loop Vec-
tor)
*2
Yes
(only
2)
Yes
(only
2)
Yes Yes
Tuning
Mode Sel
T1-02
Motor rated
power
Set the output power of the
motor in Kilowatts.
10% to 200%
of Inverter
rated output
*3
Same as
Inverter
rated out-
put
Yes Yes Ye s Ye s
Mtr Rated
Power
T1-03
Motor rated
voltage
Set the rated voltage of the
motor.
*4
0 to 255.0 V
(200 V class)
0 to 510.0 V
(400 V class)
200.0 V
(200 V
class)
400.0 V
(400 V
class)
––YesYes
Rated
Voltage
T1-04
Motor rated
current
Set the rated current of the motor
in Amps.
10% to 200%
of Inverter
rated
current
*3
Same as
general-
purpose
motor with
same
capacity as
Inverter
Yes Yes Ye s Ye s
Rated
Current
T1-05
Motor rated
frequency
Set the base frequency of the
motor.
*4
0 to 150.0 Hz
*5
50.0 Hz – – Yes Yes
Rated
Frequency
T1-06
Number of
motor poles
Set the number of motor poles. 2 to 48 poles 4 poles – – Yes Yes
Number of
poles
T1-07
Motor rated
speed
Set the base speed of the motor
in r/min.
0 to 24000
1750
r/min
––YesYes
Rated
Speed
T1-08
Number of
PG pulses
per revolu-
tion
Sets the number of pulses for the
PG (pulse generator or encoder)
per motor revolution without a
multiplication factor
0 to 60000 1024 - Yes - Yes
PG Pulses/
Rev
To Next Page
