SOCT Copernicus PLUS - Service Manual
102
Voltages on power supplying plug X1
Plug
Pins
Voltage DC
X1
X1.1 - X1.2
- (22V – 25V)
X1.3 - X1.2
+ (22V – 25V)
Description of connectors on board 151-517
Plug
Function
X1
Powering socket
X2
USB controller
X3
Y axis movement transoptor
X4
Z axis movement transoptor
X5
X axis movement transoptor
X6
Communication socket
(communicates with board 151-506)
X7
X axis engine powering
X8
Y axis engine powering
X9
Z axis engine powering
X10
Chinrest axis engine powering
JP1
Programming jumper
