SOCT Copernicus PLUS - Service Manual

8.3.4 Microsoft Visual C++ Redistributable installation

Insert a CD with SOCT Copernicus + software to the CD-ROM.

Open the disc and double click on the vcredist_x86_vc2008.exe.

Press Next>>.

Select I have read and accept the license terms then press Install >>.
