SOCT Copernicus PLUS - Service Manual
17
8.2 NI Frame Grabber card and WinFast card installation
Open the left side cover of a PC.
Plug in the NI Frame Grabber into the PCI slot #2 then secure the card using a screw.
Plug the WinFast Video card into the PCI slot #1 then secure the card using a screw.
Close the PC cover.
