SOCT Copernicus PLUS - Service Manual
106
12.9 Scanner controlling boards
Both scanners controls boards are equipped with diodes.
If diode shining colour is:
Green- Scanners are turned on, and Works properly
Red – Scanner error, system malfunction
Orange – Scanners are turned off
Diodes signalizing scanner’s status
Scanner powering control
