9. Troubleshooting
9.1 Mechanical troubleshooting
Plug the Power cord and turn
on the device
Does unit start?
Have Coppernicus PLUS
positioned itself in the middle
position?
Can chinrest perform up and
down movement?
Can SOCT head perform left
and right movement?
Can SOCT head perform up
and down movement?
Yes
Yes
Yes
Yes
Yes
Yes
Yes
See: Fuse Exchange,
See: Electronic troubleshooting
Protect handle is still In device,
(see: Removing protect handle)
See: Movement modules
See: Chinrest module
See: Movement modules
See: Backward and forward
movement engine
See: Movement modules
See: Left and right movement
engine
See: Movement modules
See: Up and down movement
engine
No
No
No
No
No
No
End of examination
Can SOCT head perform
backward and forward
movement?
