SOCT Copernicus PLUS - Service Manual
Now one can remove the cover by lifting it up gently. The SOCT’s Copernicus+ four legs are locked at
two metal rails by clamps. There are only two removable clamps at a side. First remove screws from
the clamps and then remove metal holders. This operation is shown in a figure below.
Now shift SOCT Copernicus+ to the left and then lift it up. Put the SOCT on the flat stable table.
Important!
It is strongly recommended to wait at least one hour before turning the device on for the first
time after delivery. It is very important in case where the delivery was made during low outside
temperatures or high humidity.
7.2 Connecting cables
After unpacking, one should check the whole set for any mechanical damages, cables
damages, etc. In case when any damage is found, don't connect the device and contact
your local distributor.
