Optopol SOCT Copernicus + - Page 191

SOCT Copernicus PLUS - Service Manual
191
19. 1
8
SOCT
Transportation
box
(base only)
D003P
20.
X movement
toothed bar
D004P
X movement
toothed bar
21.
Y movement
toothed bar
D005P
Y movement
toothed bar
22.
Z movement
toothed bar
D006P
Z movement
toothed bar
23.
Movement
engine rack
D007P
Movement engine
rack
24.
Metal brackets
for SOCT
transportation
box
D008P
25. 1
9
Switch source
power supply
E001P
26. 2
0
Main controller
board (CPU)
(151-506)
E002P
DEPENDS FROM
SERIALN NUMBER
