SOCT Copernicus PLUS - Service Manual
194
41. 3
3
Scanner set Y
(Scanner +
Cable +
Controller )
E017YP
42.
Scanner X cable
E018XP
43.
Scanner Y cable
E018YP
44. 3
4
X scanner
mirror
E019P
45. 3
5
Y scanner
mirror
E020P
46.
Micro switches
with screws for
chinrest
E021P
Set
47. 4
2
Preview camea
E023P
