Remove PCIe Card Cables From Secondary HBA PCIe Card
1.
Reconnect the PCIe card cables.
a.
Reconnect the two PCIe card cables to the primary HBA PCIe card and the
connectors on the motherboard [2].
Notice that there are two sets of connectors on the motherboard. Be sure to connect the
cables to the connector on the right in each set (looking at the connectors from the rear of
the server node).
b.
Position the server node's front cover onto the server node and tighten
the three green, captive Phillips screws that secure the server node's front
cover to the motherboard [1].
2.
Return the server node to operation.
a.
Install the server node top cover.
See “Installing the Server Node Top Cover” on page 245.
b.
Install the server node into the system.
See “Installing a Server Node Into the System Chassis” on page 246.
c.
Power on the server node.
See “Powering On Oracle Database Appliance Version 1” on page 249.
Remove PCIe Card Cables From Secondary HBA PCIe Card
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes removing secondary HBA PCIe card cables from Oracle Database
Appliance Version 1.
1.
Prepare the server node for service.
a.
Attach an antistatic wrist strap.
See “Performing Electrostatic Discharge and Antistatic Prevention
Measures” on page 146.
232 Oracle Database Appliance Service Manual • November 2017
