Adding Optional Oracle Database Appliance X7-2-HA Storage Shelf Drives (CRU)
Note - Replace filler panels with drives one at a time to ensure proper storage shelf chassis
cooling.
b.
Open the drive lever of the new drive by pressing the release button on the
drive.
c.
Slide the new drive into the drive slot [1] until it engages with the backplane
connector. Then close the lever to fully seat the drive and lock it into place
[2].
Chapter 3 • Servicing CRUs That Do Not Require System Power Off 81
