How to Install Optional PCIe Slot Cards in Order
FIGURE 31
ZS3-2 Controller Serial Management Port
ZS3-2 Network Management Port
The network management connector (NET MGT) is an RJ-45 port and provides an alternate
terminal interface to the SP console.
FIGURE 32
ZS3-2 Controller Network Management Port
ZS3-2 Ethernet Ports
The ZS3-2 has four RJ-45 10-Gigabit Ethernet (10GbE) network connectors, labeled NET 3,
NET 2, NET 1, and NET 0 (left to right) on the rear panel. The ports operate at 100 Mbits/sec,
1000 Mbits/sec, or 10-Gbits/sec. Use these ports to connect the appliance to the network.
Servicing the Hardware 125
