Servicing the 7x20 Controller
7320 I/O Components
The following figure and legend identify the I/O components of the storage controller.
FIGURE 51
7320 Controller I/O Components
Figure Legend
1 Top cover 2 Left Control Panel Light Pipe Assembly
3 Drive Cage 4 Solid State Drives
5 blank/USB Module 6 Right Control Panel Light Pipe Assembly
7320 PCIe Cards and Risers
Following is the complete list of replaceable PCIe cards for the 7320 system.
180 Oracle ZFS Storage Appliance Customer Service Manual • February 2016
