Oracle DE2-24 - Disk Shelf I;O Module Indicators

Servicing the Disk Shelves
FIGURE 74
Sun Disk Shelf Back Panel
Figure Legend
1 Power supply modules with built-in fans. Power supply 0 is on the left and power supply 1 is on the right.
2 Removable SAS Interface Module (SIM) Boards. SIM 0 is on the left, and SIM 1 is on the right.
Disk Shelf I/O Module Indicators
The following disk shelves have I/O Modules (IOMs):
■
Oracle Storage Drive Enclosure DE2-24P
■
Oracle Storage Drive Enclosure DE2-24C
