How to Replace a 7x20 Controller PCIe Card or Riser
How to Replace a 7x20 Controller PCIe Card or Riser
Caution - This procedure requires that you handle components that are sensitive to static
discharge, which can cause the component to fail. To avoid damage, wear an antistatic wrist
strap and use an antistatic mat when handling components. Note that the 7120 Sun Flash
Accelerator F20 card is a FRU and must be replaced by an Oracle service representative.
Go to the Maintenance > Hardware screen of the BUI and click the right-arrow icon on the
controller, and then click Slots to locate the faulted component. All HBAs must be of the same
type. Ensure that you upgrade your system software before installing a newly released HBA.
1.
Power off the storage controller as described in “How to Power off the
Controller” on page 41.
2.
Extend the controller from the rack as described in “How to Extend the Storage
Controller from the Rack” on page 41.
3.
7120 or 7320: To remove the top cover:
a.
Unlatch the fan module door, pull the two release tabs back, rotate the fan
door to the open position and hold it there.
b.
Press the top cover release button and slide the top cover to the rear about
a half-inch (1.3 cm).
c.
Lift up and remove the top cover.
4.
7420: To remove the top cover:
Servicing the Hardware 217
