How to Replace a ZS3-4 PCIe Card or Riser
How to Replace a ZS3-4 PCIe Card or Riser
Caution - This procedure requires that you handle components that are sensitive to static
discharge, which can cause the component to fail. To avoid damage, wear an antistatic wrist
strap and use an antistatic mat when handling components.
Go to the Maintenance > Hardware screen of the BUI and click the right-arrow icon on the
controller, and then click Slots to locate the faulted component. All HBAs must be of the same
type. Ensure that you upgrade your system software before installing a newly-released HBA.
1.
Shut down the controller using one of the power-off methods described in “How
to Power off the Controller” on page 41.
2.
Extend the controller from the rack as described in “How to Extend the Storage
Controller from the Rack” on page 41.
3.
Remove the top cover as described in “How to Remove the Top
Cover” on page 42.
4.
Locate the PCIe card position in the storage controller, see “ZS3-4 PCIe
Options” on page 86.
5.
To replace the PCIe card:
Servicing the Hardware 105
