Servicing the Disk Shelves
FIGURE 76
SIM Board Indicators
Figure Legend Figure Legend
1 AC power indicator 6 Power switch
2 DC power indicator 7 Port fault indicator
3 Fan fault indicator 8 Port OK indicator
4 Power supply fault indicator 9 SIM board OK indicator (green)/SIM board fault
indicator (amber)
5 Universal power connector 10 SIM locator indicator
Disk Shelf Power Supply Indicators
The following figure shows power supply with fan module indicators for these disk shelves:
■
Oracle Storage Drive Enclosure DE2-24P
■
Oracle Storage Drive Enclosure DE2-24C
Servicing the Hardware 245
