How to Replace a ZS3-2 PCIe Card or Riser
The Maintenance > Hardware screen of the BUI provides status of the replacement on the
Details page for DIMMs.
How to Replace a ZS3-2 PCIe Card or Riser
Caution - This procedure requires that you handle components that are sensitive to static
discharge, which can cause the component to fail. To avoid damage, wear an antistatic wrist
strap and use an antistatic mat when handling components.
Removing a PCIe card is a cold-service operation. You must power off the appliance before you
remove the card. There will be a loss of access to the storage unless the system is in a clustered
configuration.
1.
To locate a faulted component, go to the Maintenance > Hardware screen of the
BUI and click the right-arrow icon on the controller, and then click Slots.
2.
Power off the storage controller as described in “How to Power off the
Controller” on page 41.
3.
Extend the controller from the rack as described in “How to Extend the Storage
Controller from the Rack” on page 41.
4.
Remove the top cover as described in “How to Remove the Top
Cover” on page 42.
5.
Locate the PCIe card position in the storage controller, see “ZS3-2 PCIe
Options” on page 123.
146 Oracle ZFS Storage Appliance Customer Service Manual • February 2016
