Servicing the ZS3-2 Controller
Figure Legend
1 PDB signal cable 3 Drive signal cable 5 Drive power cable
2 USB board cable 4 LED board cable
ZS3-2 Motherboard, Memory, and PCIe Cards
The ZS3-2 controller motherboard, memory, and PCIe components are described in the
following figure and legend.
Note - Field replaceable components (FRUs) are not customer-serviceable, and must be
replaced by trained Oracle service technicians.
Servicing the Hardware 119
