Servicing the ZS3-4 Controller
Mktg Part Number Description
7100488 2-port 10Gb Ethernet Copper Base-T
X4242A 2-port InfiniBand CX2 HCA
X1109A-Z 2-port 10GbE SFP+ NIC
X2129A Transceiver 850NM, 1/10GPS, Short Reach, SFP
X5562A-Z Transceiver 10GbE/1GbE, Long Reach, SFP
ZS3-4 PCIe Options
This table describes the PCIe base configuration and optional slot assignments for ZS3-4
standalone and cluster configurations.
TABLE 20
ZS3-4 Controller PCIe Options
Slot Mfg Part Number Description Max Note
0 7047852 8-port SAS-2
internal HBA
1 Base configuration
1 7067091 4-port (4x4) SAS-2
external HBA
4 Base configuration
2 7067091 4-port (4x4) SAS-2
external HBA
4 Additional optional
back-end
2 7070006 2-port 10Gb Ethernet
Copper NIC
4 Optional
recommended front-
end
2 375-3696-01 2-port InfiniBand
CX2 HCA
4 Optional
recommended front-
end
2 7070195 4-port 1Gb Ethernet
Copper UTP NIC
4 Optional
recommended front-
end
2 7051223 2-port 10Gb Ethernet
Optical NIC
6 Optional
recommended front-
end
2 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or
initiator (backup)
2 7023303 2-port 16Gb FC
HBA
4 Optional FC target or
initiator (backup)
3 7070006 2-port 10Gb Ethernet
Copper NIC
4 Optional
recommended front-
end
3 375-3696-01 2-port InfiniBand
CX2 HCA
4 Optional
recommended front-
end
86 Oracle ZFS Storage Appliance Customer Service Manual • February 2016
