Servicing the ZS3-4 Controller
Slot Mfg Part Number Description Max Note
3 7070195 4-port 1Gb Ethernet
Copper UTP NIC
4 Optional
recommended front-
end
3 7051223 2-port 10Gb Ethernet
Optical NIC
6 Optional
recommended front-
end
3 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or
initiator (backup)
3 7023303 2-port 16Gb FC
HBA
4 Optional FC target or
initiator (backup)
4 7070006 2-port 10Gb Ethernet
Copper NIC
4 Optional
recommended front-
end
4 375-3696-01 2-port InfiniBand
CX2 HCA
4 Optional
recommended front-
end
4 7070195 4-port 1Gb Ethernet
Copper UTP NIC
4 Optional
recommended front-
end
4 7051223 2-port 10Gb Ethernet
Optical NIC
6 Optional
recommended front-
end
4 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or
initiator (backup)
4 7023303 2-port 16Gb FC
HBA
4 Optional FC target or
initiator (backup)
C 511-1496-05 Cluster Controller
200
1 Cluster base
configuration
5 7070006 2-port 10Gb Ethernet
Copper NIC
4 Optional
recommended front-
end
5 375-3696-01 2-port InfiniBand
CX2 HCA
4 Optional
recommended front-
end
5 7070195 4-port 1GbE UTP
Ethernet
4 Optional
recommended front-
end
5 7051223 2-port 10Gb Ethernet
Optical NIC
6 Optional
recommended front-
end
5 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or
initiator (backup)
5 7023303 2-port 16Gb FC
HBA
4 Optional FC target or
initiator (backup)
Servicing the Hardware 87
