Servicing the ZS3-4 Controller
Slot Mfg Part Number Description Max Note
6 7070006 2-port 10Gb Ethernet
Copper NIC
4 Optional
recommended front-
end
6 375-3696-01 2-port InfiniBand
CX2 HCA
4 Optional
recommended front-
end
6 7070195 4-port 1Gb Ethernet
Copper UTP NIC
4 Optional
recommended front-
end
6 7051223 2-port 10Gb Ethernet
Optical NIC
6 Optional
recommended front-
end
6 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or
initiator (backup)
6 7023303 2-port 16Gb FC
HBA
4 Optional FC target or
initiator (backup)
7 7067091 4-port (4x4) external
HBA
4 Additional optional
back-end
7 7070006 2-port 10Gb Ethernet
Copper NIC
4 Optional
recommended front-
end
7 371-4325-02 2-port 8Gb FC HBA 4 Optional
recommended front-
end
7 375-3696-01 2-port InfiniBand
CX2 HCA
4 Optional
recommended front-
end
7 7051223 2-port 10Gb Ethernet
Optical NIC
6 Optional
recommended front-
end
7 7070195 4-port 1Gb Ethernet
Copper UTP NIC
4 Optional
recommended front-
end
7 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or
initiator (backup)
7 7023303 2-port 16Gb FC
HBA
4 Optional FC target or
initiator (backup)
8 7067091 4-port (4x4) SAS-2
external HBA
4 Base configuration
9 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or
initiator (backup)
9 7070006 2-port 10Gb Ethernet
Copper NIC
4 Optional
recommended front-
end
88 Oracle ZFS Storage Appliance Customer Service Manual • February 2016
