Servicing the ZS4-4 Controller
through 5, in that order. A filler panel must be installed in empty drive slots. The system drive
LEDs are shown in the following figure.
FIGURE 3
System Drive LEDs
TABLE 16
System Drive LEDs
Figure Legend Figure Legend Figure Legend
1 Ready to remove (blue) 2 Service action required (amber) 3 OK/Activity (green)
ZS4-4 Rear Panel
The ZS4-4 rear panel is shown in the following figure. Base configuration PCIe cards are not
depicted in this illustration.
46 Oracle ZFS Storage Appliance Customer Service Manual • February 2016
