Servicing the Disk Shelves
FIGURE 78
Sun Disk Shelf Power Supply Indicators
Figure Legend Figure Legend
1 Cooling fan status indicator 6 Power cord tie wrap
2 AC power status indicator 7 Universal power input connector
3 DC power status indicator 8 Right ejection arm and captive screw latch
4 Power supply status indicator
5 Power on/off switch
Disk Shelf Configurations
The following tables describe and provide part numbers for the supported expansion storage
shelves.
Oracle Storage Drive Enclosure DE2-24P
The following sections describe disk shelf components.
